Detail produk:
|
Color Temperature(CCT): | 2700k-6500k | Lamp Luminous Efficiency(lm/w): | 80 |
---|---|---|---|
Color Rendering Index(Ra): | 80 | Support Dimmer: | Yes |
Lighting solutions service: | Project Installation | Lifespan (hours): | 50000 |
Working Time (hours): | 50000 | Product Weight(kg): | 0.42 |
Warranty(Year): | 2-Year | Input Voltage(V): | DC 12v/24v/100-240vac |
Lamp Luminous Flux(lm): | 80 | CRI (Ra>): | 80 |
Working Temperature(℃): | -20 - 40 | Working Lifetime(Hour): | 50000 |
Lamp Body Material: | Stainless steel | IP Rating: | IP67, IP67 Waterproof |
Application: | Step,stair,Deck,Boat,Humid environment | Light Source: | LED |
Item Type: | LED Underground Light | Transport Package: | Shockproof Carton Box |
Glass: | PMMA Diffuser | OEM&ODM: | Available |
LED Source: | 1X1W/2W/3W | Lens effciency: | ≥85% |
Shape: | Round | Feature: | Semi-shading LED Underground light |
Menyoroti: | LED Underground Light Semi Shading,Lampu LED Di Bawah Tanah,IP67 Di Lampu LED Tanah |
Item No.
|
Sumber cahaya
|
sudut balok ((°)
|
Konsumsi
|
Tegangan Masuk ((V)
|
Ik rate
|
HE82511
|
1*1W LED
|
8°/15°/30°/45°/60°
|
1.2
|
DC12V/DC24V
AC100-240V |
8
|
HE82511
|
1*3W LED
|
8°/15°/30°/45°/60°
|
3
|
DC12V/DC24V
AC100-240V |
8
|
HE82516
|
1*3W RGB3in1 LED
|
8°/15°/30°/45°/60°
|
1.2
|
DC12V/DC24V
AC100-240V |
8
|
HE82519
|
1*4W RGBW4in1 LED
|
30°/45°/60°
|
4.5
|
DC12V/DC24V
|
8
|
Spesifikasi bahan
|
|
|
Perumahan
|
Aluminium paduan yang diekstrusi # 6063, oksidasi anodik atau pewarna bubuk luar ruangan
|
|
Sampul depan
|
Aluminium untuk lukisan bubuk luar
|
|
Lensa
|
Lensa optik,efisiensi ≥85%
|
|
Kaca
|
Diffuser PMMA
|
|
Kapasitas tekanan kaca
|
> 1800 kg
|
|
Gasket
|
Segel ganda silikon berbentuk cetakan
|
|
Suhu operasi
|
(-20°C~40°C)
|
|
Kabel listrik
|
H05RN-F2*0.75mm2L=0.5m ((tekanan rendah)
H05RN-F3*0.75mm2L=0.5m ((untuk warna tunggal/tekanan tinggi) H05RN-F5*0.5mm2L=0.5m ((untuk RGBW) |
|
Sleeve pemasangan
|
ABS
|
